Basic Info.
Model NO.
HF T40/60
Power Supply
Electric
Keyword
Sprayer Drone
Power Battery
14s/18s 30000mAh *1
Atomization Range
60-250μm Adjustable
Nozzle Type
Centrifugal Nozzle
Spreader
Optional
Product Description
| Basic Parameters | ||
| Model | HF T40 | HF T60 |
| Material | Aviation carbon fiber+aviation aluminum | |
| Unfolded Size | 2560*2460*825mm | 3060*3050*860mm |
| Folded Size | 940*730*825mm | 1110*850*860mm |
| Max.Takeoff Weight | 72kg | 106 kg |
| Maximum load capacity | 35kg | 55kg |
| Aircraft self weight | 25 kg | 35 kg |
| Medicine box capacity | 35 L | 55L |
| Flight speed | 1-10 m/s | |
| Spray width | 6-10 m | 8-12 m |
| Endurance | 10-13 min (full load) | 10-13 min (full load) |
| Spray flow rate | 3-10L/min | 4.5 L/min |
| Atomized particle size | 60~90μm | 80-250μm |
| Working efficiency | 2 ha/Sorties | 3.3 ha/Sorties |
| Battery capacity | 14S 30000mah*1 | 18S 30000mah *1 |
| Charging time | 18-20min | |
| Flight control | Industrial version GPS and controller | |
| Wind protection level | ≤5 | |
| Power system | 68.4V power polymer computer battery | |
| Centrifugal Nozzle | ||
| Model | HF T40 | HF T60 |
| Spray Width | 6-10M | 8-12M |
| Spray flow rate | 3-10L/min | 4.5 L/min |
| Atomized particle size | 60~90μm | 80-250μm |
| Efficiency | 2 ha/Time | 3.3 ha/Time |
·Adjustable: The size of the spray droplets can be adjusted by controlling the speed of the nozzle, achieving precision agriculture.
·Easy to Replace and Maintain: The centrifugal spray head consists of a centrifugal motor, a spray tube, and a spray disc. The spray disc is separated from the motor, preventing the motor from coming into contact with pesticides, extending the motor's lifespan.
·High Corrosion Resistance and Durability: The spray disc is made of high-quality materials that can withstand acidic and alkaline pesticides.
| Pluggable Water Tank | ||
| Model | HF T40 | HF T60 |
| Medicine box capacity | 35L | 55L |
| Spray flow rate | 3-10L/min | 4.5 L/min |
| Atomized particle size | 60~90μm | 80-250μm |
| Efficiency | 2 ha/Time | 3.3 ha/Time |
| 1080P HD FPV Camera | |
| Resolution | 1080P |
| FPV | First Person View |
| Gimbal | With stabilization |
| Camera Type | Super wide-angle |
| FOV (Field of View) | Ultra wide-angle |
| Industrial Grade | Designed for industrial applications |
| Three-proof | Waterproof, Dustproof, Shockproof |
| Obstacle Avoidance Radar | |
| Radar Type | Tri-directional |
| Precision | High Precision |
| Obstacle Avoidance | Yes |
| Remote Controller | |
| Screen Size | 5.5 inch |
| Cooling System | Built-in cooling system |
| Run Time | Greater than 6 hours |
| Charging Time | Less than 2 hours |
| Network Connectivity | Supports multiple network connection methods such as WiFi, 4G, etc. |
| Dual Antenna | Dual antenna signals complement each other, ultra-high sensitivity |
| Signal Enhancement | Greatly enhances communication capability for weak signals |
| Transmission Distance | Ultra long distance transmission, control radius over 5 km |
| IP Rating | IP67 protection capability, dustproof, anti-splash |
| Spreading System (Optional) | ||
| Parameter | HF T40 | HF T60 |
| Spreading Tank Capacity | 50L | 70L |
| Functions | Spreading solid fertilizer, seeds,fish food etc... | |
| Interchangeable System | Integrated spraying system can quickly be swapped with spreading system | |
| Drive Shaft Design | Upper and lower segmented drive shaft design | |
| Screw Design | Externally screwed screws | |
| Disassembly/Assembly | Easily disassembled and assembled from outside | |
| Motor Wiring | External wiring to prevent fertilizers and liquids from entering electric control hatch | |
